Headtube Chip
Rear Tuning Chip
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 433 | 454 | 467 | 487 |
| Stack | 581 | 595 | 619 | 637 |
| Effective Top Tube (ETT) | 600 | 625 | 645 | 670 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 67.8 | 67.8 | 67.8 | 67.8 |
| Seat Tube Angle (STA) | 73.8 | 73.8 | 73.8 | 73.8 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 450 | 450 | 450 | 450 |
| BB Drop | 63 | 63 | 63 | 63 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1148 | 1174 | 1197 | 1224 |
| Trail 26x4.0" | 93 | 93 | 93 | 93 |
| Trail 27.5x4.0" | 101 | 101 | 101 | 101 |
| Trail 29x2.6" | 99 | 99 | 99 | 99 |
| Standover 26x4.0" | 691 | 724 | 764 | 801 |
| Standover 27.5x4.0" | 711 | 744 | 784 | 821 |
| Standover 29x2.6" | 706 | 739 | 779 | 816 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 435 | 456 | 469 | 489 |
| Stack | 580 | 594 | 618 | 636 |
| Effective Top Tube (ETT) | 600 | 625 | 645 | 670 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 68 | 68 | 68 | 68 |
| Seat Tube Angle (STA) | 74 | 74 | 74 | 74 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 440 | 440 | 440 | 440 |
| BB Drop | 61 | 61 | 61 | 61 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1138 | 1165 | 1188 | 1215 |
| Trail 26x4.0" | 92 | 92 | 92 | 92 |
| Trail 27.5x4.0" | 100 | 100 | 100 | 100 |
| Trail 29x2.6" | 98 | 98 | 98 | 98 |
| Standover 26x4.0" | 693 | 726 | 766 | 803 |
| Standover 27.5x4.0" | 713 | 746 | 786 | 823 |
| Standover 29x2.6" | 708 | 741 | 781 | 818 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 436 | 457 | 470 | 490 |
| Stack | 579 | 593 | 617 | 635 |
| Effective Top Tube (ETT) | 600 | 625 | 645 | 670 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 68.2 | 68.2 | 68.2 | 68.2 |
| Seat Tube Angle (STA) | 74.2 | 74.2 | 74.2 | 74.2 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 430 | 430 | 430 | 430 |
| BB Drop | 59 | 59 | 59 | 59 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1129 | 1155 | 1178 | 1205 |
| Trail 26x4.0" | 91 | 91 | 91 | 91 |
| Trail 27.5x4.0" | 99 | 99 | 99 | 99 |
| Trail 29x2.6" | 97 | 97 | 97 | 97 |
| Standover 26x4.0" | 693 | 726 | 766 | 803 |
| Standover 27.5x4.0" | 713 | 746 | 786 | 823 |
| Standover 29x2.6" | 708 | 741 | 781 | 818 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 422 | 443 | 456 | 476 |
| Stack | 579 | 593 | 617 | 635 |
| Effective Top Tube (ETT) | 590 | 615 | 635 | 660 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 67.8 | 67.8 | 67.8 | 67.8 |
| Seat Tube Angle (STA) | 73.8 | 73.8 | 73.8 | 73.8 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 450 | 450 | 450 | 450 |
| BB Drop | 61 | 61 | 61 | 61 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1139 | 1165 | 1188 | 1215 |
| Trail 26x4.0" | 94 | 94 | 94 | 94 |
| Trail 27.5x4.0" | 102 | 102 | 102 | 102 |
| Trail 29x2.6" | 100 | 100 | 100 | 100 |
| Standover 26x4.0" | 693 | 726 | 766 | 803 |
| Standover 27.5x4.0" | 713 | 746 | 786 | 823 |
| Standover 29x2.6" | 708 | 741 | 781 | 818 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 424 | 445 | 458 | 478 |
| Stack | 578 | 592 | 616 | 634 |
| Effective Top Tube (ETT) | 590 | 615 | 635 | 660 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 68 | 68 | 68 | 68 |
| Seat Tube Angle (STA) | 74 | 74 | 74 | 74 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 440 | 440 | 440 | 440 |
| BB Drop | 59 | 59 | 59 | 59 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1129 | 1156 | 1178 | 1206 |
| Trail 26x4.0" | 93 | 93 | 93 | 93 |
| Trail 27.5x4.0" | 101 | 101 | 101 | 101 |
| Trail 29x2.6" | 99 | 99 | 99 | 99 |
| Standover 26x4.0" | 693 | 726 | 766 | 803 |
| Standover 27.5x4.0" | 713 | 746 | 786 | 823 |
| Standover 29x2.6" | 708 | 741 | 781 | 818 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 425 | 446 | 459 | 479 |
| Stack | 576 | 590 | 615 | 633 |
| Effective Top Tube (ETT) | 590 | 615 | 635 | 660 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 68.2 | 68.2 | 68.2 | 68.2 |
| Seat Tube Angle (STA) | 74.2 | 74.2 | 74.2 | 74.2 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 430 | 430 | 430 | 430 |
| BB Drop | 57 | 57 | 57 | 57 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1119 | 1146 | 1169 | 1196 |
| Trail 26x4.0" | 92 | 92 | 92 | 92 |
| Trail 27.5x4.0" | 100 | 100 | 100 | 100 |
| Trail 29x2.6" | 98 | 98 | 98 | 98 |
| Standover 26x4.0" | 695 | 728 | 768 | 805 |
| Standover 27.5x4.0" | 715 | 748 | 788 | 825 |
| Standover 29x2.6" | 710 | 743 | 783 | 820 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 434 | 454 | 467 | 486 |
| Stack | 578 | 592 | 616 | 634 |
| Effective Top Tube (ETT) | 598 | 622 | 642 | 667 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 66.9 | 66.9 | 66.9 | 66.9 |
| Seat Tube Angle (STA) | 74.2 | 74.2 | 74.2 | 74.2 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 450 | 450 | 450 | 450 |
| BB Drop | 64.5 | 64.5 | 64.5 | 64.5 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1157 | 1183 | 1206 | 1233 |
| Trail 26x4.0" | 100 | 100 | 100 | 100 |
| Trail 27.5x4.0" | 108 | 108 | 108 | 108 |
| Trail 29x2.6" | 106 | 106 | 106 | 106 |
| Standover 26x4.0" | 688 | 721 | 761 | 798 |
| Standover 27.5x4.0" | 708 | 741 | 781 | 818 |
| Standover 29x2.6" | 703 | 736 | 776 | 813 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 435 | 456 | 469 | 488 |
| Stack | 577 | 591 | 615 | 633 |
| Effective Top Tube (ETT) | 598 | 622 | 642 | 667 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 67 | 67 | 67 | 67 |
| Seat Tube Angle (STA) | 74.3 | 74.3 | 74.3 | 74.3 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 440 | 440 | 440 | 440 |
| BB Drop | 62.5 | 62.5 | 62.5 | 62.5 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1147 | 1174 | 1197 | 1224 |
| Trail 26x4.0" | 99 | 99 | 99 | 99 |
| Trail 27.5x4.0" | 107 | 107 | 107 | 107 |
| Trail 29x2.6" | 105 | 105 | 105 | 105 |
| Standover 26x4.0" | 689 | 722 | 762 | 800 |
| Standover 27.5x4.0" | 709 | 742 | 782 | 820 |
| Standover 29x2.6" | 704 | 737 | 777 | 815 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 437 | 457 | 470 | 490 |
| Stack | 576 | 590 | 614 | 632 |
| Effective Top Tube (ETT) | 598 | 622 | 642 | 667 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 67.1 | 67.1 | 67.1 | 67.1 |
| Seat Tube Angle (STA) | 74.5 | 74.5 | 74.5 | 74.5 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 430 | 430 | 430 | 430 |
| BB Drop | 60.5 | 60.5 | 60.5 | 60.5 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1138 | 1164 | 1187 | 1214 |
| Trail 26x4.0" | 98 | 98 | 98 | 98 |
| Trail 27.5x4.0" | 106 | 106 | 106 | 106 |
| Trail 29x2.6" | 104 | 104 | 104 | 104 |
| Standover 26x4.0" | 690 | 723 | 763 | 801 |
| Standover 27.5x4.0" | 710 | 743 | 783 | 821 |
| Standover 29x2.6" | 705 | 738 | 778 | 816 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 421 | 443 | 456 | 476 |
| Stack | 581 | 595 | 620 | 638 |
| Effective Top Tube (ETT) | 592 | 617 | 638 | 663 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 68.9 | 68.9 | 68.9 | 68.9 |
| Seat Tube Angle (STA) | 73.5 | 73.5 | 73.5 | 73.5 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 450 | 450 | 450 | 450 |
| BB Drop | 59.5 | 59.5 | 59.5 | 59.5 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1130 | 1156 | 1179 | 1206 |
| Trail 26x4.0" | 87.5 | 87.5 | 87.5 | 87.5 |
| Trail 27.5x4.0" | 95 | 95 | 95 | 95 |
| Trail 29x2.6" | 93 | 93 | 93 | 93 |
| Standover 26x4.0" | 696 | 728 | 768 | 805 |
| Standover 27.5x4.0" | 716 | 748 | 788 | 825 |
| Standover 29x2.6" | 711 | 743 | 783 | 820 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 423 | 444 | 458 | 478 |
| Stack | 580 | 594 | 619 | 637 |
| Effective Top Tube (ETT) | 592 | 617 | 638 | 663 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 69 | 69 | 69 | 69 |
| Seat Tube Angle (STA) | 73.7 | 73.7 | 73.7 | 73.7 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 440 | 440 | 440 | 440 |
| BB Drop | 57.5 | 57.5 | 57.5 | 57.5 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1120 | 1147 | 1169 | 1197 |
| Trail 26x4.0" | 86.5 | 86.5 | 86.5 | 86.5 |
| Trail 27.5x4.0" | 94 | 94 | 94 | 94 |
| Trail 29x2.6" | 92 | 92 | 92 | 92 |
| Standover 26x4.0" | 697 | 729 | 769 | 806 |
| Standover 27.5x4.0" | 717 | 749 | 789 | 826 |
| Standover 29x2.6" | 712 | 744 | 784 | 821 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 424 | 446 | 459 | 479 |
| Stack | 579 | 593 | 618 | 636 |
| Effective Top Tube (ETT) | 592 | 617 | 638 | 663 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 69.1 | 69.1 | 69.1 | 69.1 |
| Seat Tube Angle (STA) | 73.8 | 73.8 | 73.8 | 73.8 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 430 | 430 | 430 | 430 |
| BB Drop | 55.5 | 55.5 | 55.5 | 55.5 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1110 | 1137 | 1160 | 1187 |
| Trail 26x4.0" | 85.5 | 85.5 | 85.5 | 85.5 |
| Trail 27.5x4.0" | 93 | 93 | 93 | 93 |
| Trail 29x2.6" | 91 | 91 | 91 | 91 |
| Standover 26x4.0" | 698 | 731 | 771 | 808 |
| Standover 27.5x4.0" | 718 | 751 | 791 | 828 |
| Standover 29x2.6" | 713 | 746 | 786 | 823 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 434 | 455 | 467 | 486 |
| Stack | 576 | 589 | 613 | 631 |
| Effective Top Tube (ETT) | 596 | 620 | 639 | 664 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 65.9 | 65.9 | 65.9 | 65.9 |
| Seat Tube Angle (STA) | 74.4 | 74.4 | 74.4 | 74.4 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 450 | 450 | 450 | 450 |
| BB Drop | 66 | 66 | 66 | 66 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1166 | 1192 | 1215 | 1242 |
| Trail 26x4.0" | 106.5 | 106.5 | 106.5 | 106.5 |
| Trail 27.5x4.0" | 115 | 115 | 115 | 115 |
| Trail 29x2.6" | 113 | 113 | 113 | 113 |
| Standover 26x4.0" | 685 | 718 | 758 | 795 |
| Standover 27.5x4.0" | 705 | 738 | 778 | 815 |
| Standover 29x2.6" | 700 | 733 | 773 | 810 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 436 | 456 | 468 | 488 |
| Stack | 575 | 588 | 612 | 630 |
| Effective Top Tube (ETT) | 596 | 620 | 639 | 664 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 66 | 66 | 66 | 66 |
| Seat Tube Angle (STA) | 74.6 | 74.6 | 74.6 | 74.6 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 440 | 440 | 440 | 440 |
| BB Drop | 64 | 64 | 64 | 64 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1156 | 1183 | 1206 | 1233 |
| Trail 26x4.0" | 105.5 | 105.5 | 105.5 | 105.5 |
| Trail 27.5x4.0" | 114 | 114 | 114 | 114 |
| Trail 29x2.6" | 112 | 112 | 112 | 112 |
| Standover 26x4.0" | 686 | 719 | 759 | 797 |
| Standover 27.5x4.0" | 706 | 739 | 779 | 817 |
| Standover 29x2.6" | 701 | 734 | 774 | 812 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 438 | 458 | 470 | 489 |
| Stack | 573 | 587 | 611 | 629 |
| Effective Top Tube (ETT) | 596 | 620 | 639 | 664 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 66.1 | 66.1 | 66.1 | 66.1 |
| Seat Tube Angle (STA) | 74.7 | 74.7 | 74.7 | 74.7 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 430 | 430 | 430 | 430 |
| BB Drop | 62 | 62 | 62 | 62 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1147 | 1173 | 1196 | 1223 |
| Trail 26x4.0" | 104.5 | 104.5 | 104.5 | 104.5 |
| Trail 27.5x4.0" | 113 | 113 | 113 | 113 |
| Trail 29x2.6" | 111 | 111 | 111 | 111 |
| Standover 26x4.0" | 687 | 721 | 761 | 798 |
| Standover 27.5x4.0" | 707 | 741 | 781 | 818 |
| Standover 29x2.6" | 702 | 736 | 776 | 813 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 421 | 442 | 456 | 477 |
| Stack | 584 | 598 | 623 | 641 |
| Effective Top Tube (ETT) | 594 | 620 | 641 | 666 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 69.9 | 69.9 | 69.9 | 69.9 |
| Seat Tube Angle (STA) | 73.3 | 73.3 | 73.3 | 73.3 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 450 | 450 | 450 | 450 |
| BB Drop | 58 | 58 | 58 | 58 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1120 | 1147 | 1170 | 1197 |
| Trail 26x4.0" | 81 | 81 | 81 | 81 |
| Trail 27.5x4.0" | 88 | 88 | 88 | 88 |
| Trail 29x2.6" | 86 | 86 | 86 | 86 |
| Standover 26x4.0" | 698 | 731 | 771 | 808 |
| Standover 27.5x4.0" | 718 | 751 | 791 | 828 |
| Standover 29x2.6" | 713 | 746 | 786 | 823 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 422 | 444 | 458 | 478 |
| Stack | 583 | 597 | 622 | 640 |
| Effective Top Tube (ETT) | 594 | 620 | 641 | 666 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 70 | 70 | 70 | 70 |
| Seat Tube Angle (STA) | 73.5 | 73.5 | 73.5 | 73.5 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 440 | 440 | 440 | 440 |
| BB Drop | 56 | 56 | 56 | 56 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1111 | 1137 | 1160 | 1187 |
| Trail 26x4.0" | 80 | 80 | 80 | 80 |
| Trail 27.5x4.0" | 87 | 87 | 87 | 87 |
| Trail 29x2.6" | 85 | 85 | 85 | 85 |
| Standover 26x4.0" | 699 | 732 | 772 | 809 |
| Standover 27.5x4.0" | 719 | 752 | 792 | 829 |
| Standover 29x2.6" | 714 | 747 | 787 | 824 |
| Frame Size | S | M | L | XL |
| Recommended Rider Height | 4'9" - 5'6" | 5'5" - 5'10" | 5'9" - 6'2" | 6'1" - 6'8" |
| Recommended Rider Inseam | 29" - 32" | 31" - 33" | 32" - 35" | 34" - 37" |
| Reach | 424 | 445 | 459 | 480 |
| Stack | 581 | 596 | 621 | 639 |
| Effective Top Tube (ETT) | 594 | 620 | 641 | 666 |
| Seat Tube Length C-T (STL) | 380 | 420 | 465 | 510 |
| Head Tube Angle (HTA) | 70.1 | 70.1 | 70.1 | 70.1 |
| Seat Tube Angle (STA) | 73.6 | 73.6 | 73.6 | 73.6 |
| Head Tube Length (HTL) | 95 | 110 | 136 | 156 |
| Chainstay Length | 430 | 430 | 430 | 430 |
| BB Drop | 54 | 54 | 54 | 54 |
| Fork Rake / Offset | 51 | 51 | 51 | 51 |
| Fork Axle to Crown | 485 | 485 | 485 | 485 |
| Wheelbase | 1101 | 1128 | 1151 | 1178 |
| Trail 26x4.0" | 79 | 79 | 79 | 79 |
| Trail 27.5x4.0" | 86 | 86 | 86 | 86 |
| Trail 29x2.6" | 84 | 84 | 84 | 84 |
| Standover 26x4.0" | 700 | 733 | 773 | 810 |
| Standover 27.5x4.0" | 720 | 753 | 793 | 830 |
| Standover 29x2.6" | 715 | 748 | 788 | 825 |
