The Warakin Ti is now available for pre-order. Full payment is required to reserve your Warakin Ti for arrival in mid-December. Should you change your mind before arrival, this payment is refundable less $100 to cover expedited shipping from the factory to our workshop. Our first Warakin Ti supply sold out quickly and we expect this batch to do the same. Visit our Bike Builder to get started.
The supple yet lively ride quality of steel with the corrosion resistance of titanium.
700c? Check! 650b? Double check! 29er? Triple check! Warakin has massive tire clearance.
The patent pending Tuning Chip™ system provides 20mm of chainstay length and 4mm of bottom bracket height adjustment, allowing you to fine tune your ride.
Tires & Rims
|Frame material||Seamless 3Al-2.5V B338 grade 9 titanium, internally butted front triangle|
|Bottom bracket standard||68mm BSA threaded|
|Q-factor||146mm with Shimano RS510 crankset|
|Maximum chainring size||2x 53T round; 1x 50T round or 46T oval|
|Front derailleur type||31.8mm clamp, bottom pull|
|Headset||ZS44/28.6 upper, EC44/40.0 lower|
|Internal dropper post routing||Yes. Exit port on bottom of seat tube|
|Front/rear hub standard||100x15mm thru axle / 142x12mm thru axle|
|Front/rear axle||Ø15x100mm front, TP = 1.5, TL = 15mm / Ø12x180mm rear, TP = 1.5, TL = 12mm|
|Derailleur hanger||Wolf Tooth Tuning Chip Right Dropout|
|Rear brake (rotor)||flat mount, 74mm post mount adapter available (160mm)|
|Front brake (rotor)||flat mount native, 74mm post mount adapter included (160mm)|
|Bare frame weight (54cm)||3.4lbs (1542g)|
|Fork weight (Lithic Hiili)||490g|
|Tire clearance (frame)||40mm at 420mm chainstay position, 50mm at 430/440mm chainstay position|
|Tire clearance (fork)||Max clearance 29x2.1" (54-622)|
|Braze-ons||3 bottle mounts, fender, rack, cable clamps|
|Recommended rider height||5'0"-5'2"||5'1-5'4"||5'3"-5'8"||5'7"-6'0"||5'11"-6'2"||6'1"-6'5"|
|Recommended rider inseam||27"-29"||28"-30"||30"-33"||32"-34"||33"-35"||34"-37"|
|Effective top tube||510mm||530mm||545mm||565mm||580mm||600mm|
|Nominal head tube angle||70°||70.5°||71°||71.5°||72°||72°|
|Tuning Chip induced head/seat tube angle change||±0.2°||±0.2°||±0.2°||±0.2°||±0.2°||±0.2°|
|Head tube length||87mm||95mm||115mm||140mm||165mm||185mm|
|Nominal seat tube angle||75°||74.5°||74°||73°||72.5°||72°|
|Seat tube length||470mm||505mm||530mm||550mm||570mm||590mm|
|Bottom bracket drop||68-72mm||68-72mm||68-72mm||68-72mm||68-72mm||68-72mm|
|Wheelbase||1010 - 1030mm||1017-1037mm||1023-1043mm||1028-1048mm||1032-1052mm||1046-1066mm|
|Rigid fork axle to crown length||420mm||420mm||420mm||420mm||420mm||420mm|
